Load manual feeder with [paper size]
Try one or more of the following:
Load the feeder with the correct paper size.
Depending on your printer model, touch Continue or press to clear the message and continue printing.
Note: If no paper is loaded in the feeder when Continue or
is selected, then the printer manually overrides
the request, and then prints from an automatically selected tray.
Cancel the current job.
Load manual feeder with [paper type] [paper size]
Try one or more of the following:
Load the feeder with the correct paper size and type.
Depending on your printer model, touch Continue or press to clear the message and continue printing.
Note: If no paper is loaded in the feeder when Continue or
is selected, then the printer manually overrides
the request, and then prints from an automatically selected tray.
Cancel the current job.
Paper changes needed
Try one or more of the following:
Select Use current supplies to clear the message. For nontouchscreen printer models, press to confirm.
Cancel the current print job.
Remove packaging material, [area name]
1 Remove any remaining packaging material from the specified location.
2 Select Continue to clear the message and continue printing. For nontouchscreen printer models, press to
confirm.
Remove paper from standard output bin
1 Remove paper stack from the standard output bin.
2 Select Continue to clear the message and continue printing. For nontouchscreen printer models, press to
confirm.
Troubleshooting 219

Table of Contents

Other manuals for Lexmark C746

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Lexmark C746 and is the answer not in the manual?

Lexmark C746 Specifications

General IconGeneral
ColorYes
Print technologyLaser
Resolution color2400 x 600 DPI
Maximum resolution1200 x 1200 DPI
Duplex printing modeAuto/Manual
Time to first page (black, normal)9 s
Print margins (top, bottom, right, left)4.2 mm
Print speed (black, normal quality, A4/US Letter)33 ppm
Printing colorsBlack, Cyan, Magenta, Yellow
Maximum duty cycle85000 pages per month
Recommended duty cycle1500 - 9200 pages per month
Number of print cartridges1
Page description languagesMicrosoft XPS, PCL 5c, PCL 6, PDF 1.6, PostScript 3, PPDS
Paper input typePaper tray
Total input capacity650 sheets
Total output capacity300 sheets
Maximum input capacity4300 sheets
Total number of input trays2
Maximum number of input trays6
Multi-Purpose tray input capacity100 sheets
Envelopes sizes7 3/4, 9, 10, B5, C5, DL
Paper tray media typesCard stock, Envelopes, Labels, Plain paper, Transparencies
Paper tray media weight60 - 218 g/m²
Non-ISO print media sizesExecutive (184 x 267mm), Folio (media size), Letter (media size), Oficio (media size), Statement (140 x 216mm), Universal, Legal (media size)
ISO A-series sizes (A0...A9)A4, A5, A6
JIS B-series sizes (B0...B9)B5
Maximum ISO A-series paper sizeA4
Wi-FiNo
Security algorithms802.1x RADIUS, HTTPS, LEAP, MD5, PEAP, SSL/TLS
Mobile printing technologies-
Supported network protocols (IPv4)TCP/IP, AppleTalk
Supported network protocols (IPv6)TCP/IP, TCP, UDP
Standard interfacesEthernet, USB 2.0
Optional connectivityParallel, Serial (RS-232), Wireless LAN
USB 2.0 ports quantityUSB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Noise level (idle)32 dB
Maximum internal memory1536 MB
Sound pressure level (printing)54 dB
Sound pressure level (quiet mode)48 dB
DisplayLCD
CertificationCAN/CSA-C22.2 60950-1, CSA E60825-1, ICES-003 Class A, BSMI Class A, VCCI Class A, US FDA, FCC Class A, UL 60950-1, EN/IEC 60320-1, CE Class A, CB IEC 60950-1, EN 60950-1, EN/IEC 61000-3, EN 55022 Class A, EN 55024, EN/IEC 60825-1, GS (TÜV), AR S (TÜV), SMA C-tick mark Class A, CCC Class A, CISPIR 22 Class A, MIC Mark, EK Mark
Product colorBlack, White
Display diagonal2.4 \
Power consumption (off)6.8 W
Power consumption (standby)48 W
Power consumption (printing)420 W
Server operating systems supportedWindows Server 2003, Windows Server 2003 x64, Windows Server 2008, Windows Server 2008 R2, Windows Server 2008 x64, Windows Server 2012, Windows Server 2012 R2
Operating altitude0 - 3048 m
Operating temperature (T-T)16 - 32 °C
Operating relative humidity (H-H)8 - 80 %
Package depth553 mm
Package width588 mm
Package height545 mm
Package weight29700 g
Weight and Dimensions IconWeight and Dimensions
Depth400 mm
Width435 mm
Height455 mm
