Canceling a print job from the computer
For Windows users
1
Open the printers folder:
a Click , or click Start and then click Run.
b In the Start Search or Run dialog, type control printers.
c Press Enter, or click OK.
2 Doubleclick the printer icon.
3 Select the print job you want to cancel.
4 From the keyboard, press Delete.
For Macintosh users
In Mac OS X version 10.5 or later:
1 From the Apple menu, choose System Preferences > Print & Fax > Open Print Queue.
2 From the printer window, select the print job you want to cancel.
3 From the icon bar at the top of the window, click the Delete icon.
In Mac OS X version 10.4:
1 From the Finder, navigate to:
Go > Applications > Utilities
2 Doubleclick Print Center or Printer Setup Utility.
3 Doubleclick the printer icon.
4 From the printer window, select the print job you want to cancel.
5 From the icon bar at the top of the window, click Delete.
Managing your printer
Finding advanced networking and administrator information
This chapter covers basic administrative support tasks using the Embedded Web Server. For more advanced system
support tasks, see the Networking Guide on the Software and Documentation CD and the Embedded Web Server
Administrator's Guide on the Lexmark Web site at http://support.lexmark.com.
Checking the virtual display
1 Open a Web browser, and then type the printer IP address in the address field.
Notes:
View the printer IP address in the TCP/IP section in the Network/Reports menu. The IP address appears as
four sets of numbers separated by periods, such as 123.123.123.123.
Using C746x 71

Table of Contents

Other manuals for Lexmark C746

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Lexmark C746 and is the answer not in the manual?

Lexmark C746 Specifications

General IconGeneral
ColorYes
Print technologyLaser
Resolution color2400 x 600 DPI
Maximum resolution1200 x 1200 DPI
Duplex printing modeAuto/Manual
Time to first page (black, normal)9 s
Print margins (top, bottom, right, left)4.2 mm
Print speed (black, normal quality, A4/US Letter)33 ppm
Printing colorsBlack, Cyan, Magenta, Yellow
Maximum duty cycle85000 pages per month
Recommended duty cycle1500 - 9200 pages per month
Number of print cartridges1
Page description languagesMicrosoft XPS, PCL 5c, PCL 6, PDF 1.6, PostScript 3, PPDS
Paper input typePaper tray
Total input capacity650 sheets
Total output capacity300 sheets
Maximum input capacity4300 sheets
Total number of input trays2
Maximum number of input trays6
Multi-Purpose tray input capacity100 sheets
Envelopes sizes7 3/4, 9, 10, B5, C5, DL
Paper tray media typesCard stock, Envelopes, Labels, Plain paper, Transparencies
Paper tray media weight60 - 218 g/m²
Non-ISO print media sizesExecutive (184 x 267mm), Folio (media size), Letter (media size), Oficio (media size), Statement (140 x 216mm), Universal, Legal (media size)
ISO A-series sizes (A0...A9)A4, A5, A6
JIS B-series sizes (B0...B9)B5
Maximum ISO A-series paper sizeA4
Wi-FiNo
Security algorithms802.1x RADIUS, HTTPS, LEAP, MD5, PEAP, SSL/TLS
Mobile printing technologies-
Supported network protocols (IPv4)TCP/IP, AppleTalk
Supported network protocols (IPv6)TCP/IP, TCP, UDP
Standard interfacesEthernet, USB 2.0
Optional connectivityParallel, Serial (RS-232), Wireless LAN
USB 2.0 ports quantityUSB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Noise level (idle)32 dB
Maximum internal memory1536 MB
Sound pressure level (printing)54 dB
Sound pressure level (quiet mode)48 dB
DisplayLCD
CertificationCAN/CSA-C22.2 60950-1, CSA E60825-1, ICES-003 Class A, BSMI Class A, VCCI Class A, US FDA, FCC Class A, UL 60950-1, EN/IEC 60320-1, CE Class A, CB IEC 60950-1, EN 60950-1, EN/IEC 61000-3, EN 55022 Class A, EN 55024, EN/IEC 60825-1, GS (TÜV), AR S (TÜV), SMA C-tick mark Class A, CCC Class A, CISPIR 22 Class A, MIC Mark, EK Mark
Product colorBlack, White
Display diagonal2.4 \
Power consumption (off)6.8 W
Power consumption (standby)48 W
Power consumption (printing)420 W
Server operating systems supportedWindows Server 2003, Windows Server 2003 x64, Windows Server 2008, Windows Server 2008 R2, Windows Server 2008 x64, Windows Server 2012, Windows Server 2012 R2
Operating altitude0 - 3048 m
Operating temperature (T-T)16 - 32 °C
Operating relative humidity (H-H)8 - 80 %
Package depth553 mm
Package width588 mm
Package height545 mm
Package weight29700 g
Weight and Dimensions IconWeight and Dimensions
Depth400 mm
Width435 mm
Height455 mm
