88.xx [Color] cartridge critically low
The specified toner cartridge is critically low.
1 For instructions on replacing a toner cartridge, select More Information on the printer control panel.
2 Select Continue to clear the message and continue printing. For nontouchscreen printer models, press to
confirm.
88.xx [Color] cartridge very low
The specified print or toner cartridge is very low.
1 For instructions on replacing a cartridge, select More Information on the printer control panel.
2 Select Continue to clear the message and continue printing. For nontouchscreen printer models, press to
confirm.
Solving printing problems
Confidential and other held jobs do not print
These are possible solutions. Try one or more of the following:
PARTIAL JOB, NO JOB, OR BLANK PAGE PRINTS
The print job may contain a formatting error or invalid data.
Delete the print job, and then print it again.
For PDF documents, recreate the PDF and then print it again.
If you are printing from the Internet, then the printer may be reading multiple job titles as duplicates and deleting
all jobs except the first one.
For Windows users, open Print Properties. From the Print and Hold dialog, select the "Keep duplicate documents"
check box under the User name text box before entering a PIN number.
For Macintosh users, save each print job, naming each job differently, and then send the individual jobs to the
printer.
MAKE SURE THE PRINTER HAS SUFFICIENT MEMORY
Free up additional printer memory by scrolling through the list of held jobs and deleting some of them.
Error message about reading USB drive appears
Make sure the flash drive is supported.
Troubleshooting 230

Table of Contents

Other manuals for Lexmark C746

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Lexmark C746 and is the answer not in the manual?

Lexmark C746 Specifications

General IconGeneral
ColorYes
Print technologyLaser
Resolution color2400 x 600 DPI
Maximum resolution1200 x 1200 DPI
Duplex printing modeAuto/Manual
Time to first page (black, normal)9 s
Print margins (top, bottom, right, left)4.2 mm
Print speed (black, normal quality, A4/US Letter)33 ppm
Printing colorsBlack, Cyan, Magenta, Yellow
Maximum duty cycle85000 pages per month
Recommended duty cycle1500 - 9200 pages per month
Number of print cartridges1
Page description languagesMicrosoft XPS, PCL 5c, PCL 6, PDF 1.6, PostScript 3, PPDS
Paper input typePaper tray
Total input capacity650 sheets
Total output capacity300 sheets
Maximum input capacity4300 sheets
Total number of input trays2
Maximum number of input trays6
Multi-Purpose tray input capacity100 sheets
Envelopes sizes7 3/4, 9, 10, B5, C5, DL
Paper tray media typesCard stock, Envelopes, Labels, Plain paper, Transparencies
Paper tray media weight60 - 218 g/m²
Non-ISO print media sizesExecutive (184 x 267mm), Folio (media size), Letter (media size), Oficio (media size), Statement (140 x 216mm), Universal, Legal (media size)
ISO A-series sizes (A0...A9)A4, A5, A6
JIS B-series sizes (B0...B9)B5
Maximum ISO A-series paper sizeA4
Wi-FiNo
Security algorithms802.1x RADIUS, HTTPS, LEAP, MD5, PEAP, SSL/TLS
Mobile printing technologies-
Supported network protocols (IPv4)TCP/IP, AppleTalk
Supported network protocols (IPv6)TCP/IP, TCP, UDP
Standard interfacesEthernet, USB 2.0
Optional connectivityParallel, Serial (RS-232), Wireless LAN
USB 2.0 ports quantityUSB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Noise level (idle)32 dB
Maximum internal memory1536 MB
Sound pressure level (printing)54 dB
Sound pressure level (quiet mode)48 dB
DisplayLCD
CertificationCAN/CSA-C22.2 60950-1, CSA E60825-1, ICES-003 Class A, BSMI Class A, VCCI Class A, US FDA, FCC Class A, UL 60950-1, EN/IEC 60320-1, CE Class A, CB IEC 60950-1, EN 60950-1, EN/IEC 61000-3, EN 55022 Class A, EN 55024, EN/IEC 60825-1, GS (TÜV), AR S (TÜV), SMA C-tick mark Class A, CCC Class A, CISPIR 22 Class A, MIC Mark, EK Mark
Product colorBlack, White
Display diagonal2.4 \
Power consumption (off)6.8 W
Power consumption (standby)48 W
Power consumption (printing)420 W
Server operating systems supportedWindows Server 2003, Windows Server 2003 x64, Windows Server 2008, Windows Server 2008 R2, Windows Server 2008 x64, Windows Server 2012, Windows Server 2012 R2
Operating altitude0 - 3048 m
Operating temperature (T-T)16 - 32 °C
Operating relative humidity (H-H)8 - 80 %
Package depth553 mm
Package width588 mm
Package height545 mm
Package weight29700 g
Weight and Dimensions IconWeight and Dimensions
Depth400 mm
Width435 mm
Height455 mm
