Lexmark Pro715 Quick Reference Guide

12
13
21
18
19
20
L
I
N
E
E
X
T
14
15
17
16
L
IN
E
E
X
T
Use the To
12 Scanner unit Access the ink cartridges.
13 Ink cartridge access area Install, replace, or remove the ink cartridges.
14 Ethernet port Connect your printer to a computer, a local network, an external DSL, or
a cable modem.
15 USB port Connect the printer to a computer using a USB cable.
Warning—Potential Damage: Do not touch the USB port except when
plugging in or removing a USB cable or installation cable.
16 LINE port
Connect the printer to an active telephone line (through a standard wall
jack, DSL filter, or VoIP adapter) to send and receive faxes.
17 EXT port
Connect additional devices (telephone or answering machine) to the
printer and the telephone line. Use this port if you do not have a dedicated
fax line for the printer, and if this connection method is supported in your
country or region.
Note: Remove the plug to access the port.
18 Power supply with port Connect the printer to a power source using the power cord.
19 Duplex unit
• Print on both sides of a sheet of paper.
• Remove paper jams.
Use the To
20 Printhead access area Install the printhead.
Note: The carrier moves to the printhead access area when no
printhead is installed in the printer.
21 Jam clearance cover Remove jammed pages.
Using the printer control panel
1
2
3
4
5
6
7
Use To
1 Power
• Turn the printer on and off.
• Switch to Sleep mode.
Note: When the printer is on, press
to switch to Sleep mode. Press
and hold
for three seconds to turn off the printer.
2 Display
Note: The display is
turned off in Sleep
mode.
View:
• Printer status
• Messages
• Menus
3 Arrow buttons Navigate to menu or submenu items that appear on the display.
4 Home
Navigate from any level in the menu back to the home screen.
About your printer 13

Lexmark Pro715 Specifications

General

PictBridge	Yes
Dimensions (WxDxH)	465 x 403 x 251 mm
All-in-one functions	Copy, Fax, Print, Scan
Color all-in-one functions	copy, fax, print, scan
Print technology	Inkjet
Maximum resolution	4800 x 1200 DPI
Print speed (black, normal quality, A4/US Letter)	10 ppm
Print speed (color, normal quality, A4/US Letter)	6 ppm
Digital sender	No
Printing colors	Black, Cyan, Magenta, Yellow
Maximum duty cycle	10000 pages per month
Recommended duty cycle	700 pages per month
Number of print cartridges	4
Page description languages	PCL 5c, PCL 6, PDF 1.6, PostScript 3
Copier resize	25 - 400 %
Maximum copy resolution	- DPI
Copy speed (black, normal quality, A4)	14 cpm
Copy speed (color, normal quality, A4)	7 cpm
Scanner type	Flatbed & ADF scanner
Input color depth	48 bit
Maximum scan area	216 x 356 mm
Optical scanning resolution	1200 x 1200 DPI
Faxing	Color faxing
Modem speed	33.6 Kbit/s
Total input capacity	150 sheets
Maximum input capacity	700 sheets
Auto document feeder (ADF) input capacity	50 sheets
Envelopes sizes	7 3/4, 9, 10, B5, C4, DL
Photo paper sizes	10x15, 13x18 cm
Maximum print size	216 x 297 mm
Paper tray media types	Banner, Card stock, Envelopes, Iron-On Transfers, Labels, Photo paper, Plain paper
Non-ISO print media sizes	2l, Executive (184 x 267mm), Folio (media size), hagaki card, index card, l, Letter (media size), Oficio (media size), Statement (140 x 216mm)
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5
Photo paper sizes (imperial)	4x6, 5x7 \
Borderless printing media sizes	4x6, 2L, A4, B5, Hagaki card, L, Legal, Letter
Maximum ISO A-series paper size	A4
Display	LCD
Display diagonal	2.4 \
Market positioning	Home & office
Standard interfaces	Ethernet, USB 2.0, Wireless LAN
USB 2.0 ports quantity	2
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Security algorithms	802.1x RADIUS, EAP-TTLS, LEAP, MD5, PEAP, SSL/TLS
Supported network protocols (IPv4)	TCP/IP, AppleTalk, TCP UDP
Supported network protocols (IPv6)	TCP/IP
Internal memory	256 MB
Processor frequency	330 MHz
Sound pressure level (copying)	49 dB
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (average operating)	32 W
Package weight	11960 g
Mac operating systems supported	Mac OS X 10.4 Tiger, Mac OS X 10.5 Leopard, Mac OS X 10.6 Snow Leopard, Mac OS X 10.7 Lion
Linux operating systems supported	RedHat EL Linux 4.0 U5, RedHat EL Linux 4.0 U6, RedHat EL Linux 4.0 U7, RedHat EL Linux 5.0, Solaris 10 U4, Solaris 10 U5, Ubuntu 10.04, Ubuntu 9.04, Ubuntu 9.10
Server operating systems supported	Windows Server 2003, Windows Server 2003 x64, Windows Server 2008, Windows Server 2008 R2, Windows Server 2008 x64
Windows operating systems supported	Windows 7 Home Premium, Windows 7 Home Premium x64, Windows 7 Professional, Windows 7 Professional x64, Windows 7 Starter, Windows 7 Starter x64, Windows 7 Ultimate, Windows 7 Ultimate x64, Windows Vista Business, Windows Vista Business x64, Windows Vista Home Basic, Windows Vista Home Basic x64, Windows Vista Home Premium, Windows Vista Home Premium x64, Windows Vista Ultimate, Windows Vista Ultimate x64, Windows XP Home, Windows XP Home x64, Windows XP Professional, Windows XP Professional x64
Operating temperature (T-T)	16 - 32 °C
Operating relative humidity (H-H)	8 - 80 %
Sustainability certificates	ENERGY STAR
Certification	CSA, c-UL-us, ICES Class B, Executive Order 132221, CE Class B, CB IEC 60950 IEC 60825-1, GS (TÜV), SEMKO, C-tick mark Class B, V85, CCC Class B, BSMI Class B, METI(PSE), VCCI Class B, FCC Class B, UL 60950 3rd Edition, CCIB

Weight and Dimensions

Weight	9090 g
