Page #50 background imageLoading...
Page #50 background image
In Mac OS X version 10.4 or earlier
1 From the Finder, navigate to:
Applications > Internet Connect > AirPort
The SSID of the network that the computer is connected to is displayed in the Network menu.
2 Write down the SSID.
For Macintosh users with an access point
1
Type the IP address of the access point in the address field of your Web browser, and then continue
to step 2.
If you do not know the IP address of the access point, then do the following:
a From the Apple menu, navigate to:
System Preferences > Network > AirPort
b Click Advanced or Configure.
c Click TCP/IP.
The Router entry is typically the access point.
2 Type your user name and password when prompted, and then click OK.
3 In the Wireless settings section, look for the SSID.
4 Write down the SSID, security type, and the WEP key/WPA passphrase (if shown).
Notes:
Make sure you copy the network information down exactly, including any capital letters.
Store the SSID and the WEP key or WPA passphrase in a safe place for future reference.
M
AKE
SURE
YOUR
OS
IS
COMPATIBLE
WITH
WIRELESS
PRINTING
THROUGH
A
IR
P
ORT
The printer supports wireless printing only through AirPort base stations for Mac OS X version 10.5 or
later.
“Communication not available” message appears when printing
wirelessly
Try one or more of the following:
M
AKE
SURE
YOUR
COMPUTER
AND
PRINTER
HAVE
VALID
IP
ADDRESSES
FOR
THE
NETWORK
If you are using a laptop and have power saving settings enabled, then you may see the ”Communication
not available” message on your computer screen when you attempt to print wirelessly. This can occur
if the laptop hard drive has powered down.
If you see this message, then wait a few seconds and then try to print again. The laptop and printer
require a few seconds to power up again and reattach to the wireless network.
If you see this message again after you have waited long enough for the printer and the laptop to attach
to the network, then there may be a problem with your wireless network.
Make sure that the laptop and printer have both received IP addresses:
For Windows users
1 Click , or click Start and then click Run.
2 In the Start Search or Run box, type cmd.
3 Press Enter, or click OK.
4 Type ipconfig, and then press Enter.
The IP address appears as four sets of numbers separated by periods, such as 192.168.0.100.
For Macintosh users
1 From the Apple menu, navigate to:
About This Mac > More Info
2 From the Contents pane, choose Network.
3 If you are connected over a wireless network, then choose AirPort from the Active Services list.
The Router entry is typically the access point.
Locating the printer IP address
From the printer, print a network setup page.
In the TCP/IP section, look for Address.
View the printer settings.
From the printer control panel, navigate to:
> Setup > > Network Setup > > Wireless 802.11 b/g/n > > Network Connection
Setup >
> TCP/IP > > IP Address >
If the printer or the laptop does not have an IP address, or if either has an address of 169.254.x.y (where
x and y are any two numbers between 0 and 255), then do the following:
1 Turn off the device that does not have a valid IP address (the laptop, the printer, or both).
2 Turn on the device, and then check the IP addresses again.
If the printer or the laptop still does not receive a valid IP address, then there is a problem with your
wireless network. Try the following:
Make sure your access point (wireless router) is turned on and is working.
Remove any objects that could be blocking the signal.
Temporarily turn off any unnecessary wireless devices on your network and pause any
networkintensive activities, like large file transfers or network games. If the network is too busy,
then it is possible that the printer is not receiving the IP address within the allowed time.
Troubleshooting 50

Table of Contents

Other manuals for Lexmark Pro715

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Lexmark Pro715 and is the answer not in the manual?

Lexmark Pro715 Specifications

General IconGeneral
PictBridgeYes
Dimensions (WxDxH)465 x 403 x 251 mm
All-in-one functionsCopy, Fax, Print, Scan
Color all-in-one functionscopy, fax, print, scan
Print technologyInkjet
Maximum resolution4800 x 1200 DPI
Print speed (black, normal quality, A4/US Letter)10 ppm
Print speed (color, normal quality, A4/US Letter)6 ppm
Digital senderNo
Printing colorsBlack, Cyan, Magenta, Yellow
Maximum duty cycle10000 pages per month
Recommended duty cycle700 pages per month
Number of print cartridges4
Page description languagesPCL 5c, PCL 6, PDF 1.6, PostScript 3
Copier resize25 - 400 %
Maximum copy resolution- DPI
Copy speed (black, normal quality, A4)14 cpm
Copy speed (color, normal quality, A4)7 cpm
Scanner typeFlatbed & ADF scanner
Input color depth48 bit
Maximum scan area216 x 356 mm
Optical scanning resolution1200 x 1200 DPI
FaxingColor faxing
Modem speed33.6 Kbit/s
Total input capacity150 sheets
Maximum input capacity700 sheets
Auto document feeder (ADF) input capacity50 sheets
Envelopes sizes7 3/4, 9, 10, B5, C4, DL
Photo paper sizes10x15, 13x18 cm
Maximum print size216 x 297 mm
Paper tray media typesBanner, Card stock, Envelopes, Iron-On Transfers, Labels, Photo paper, Plain paper
Non-ISO print media sizes2l, Executive (184 x 267mm), Folio (media size), hagaki card, index card, l, Letter (media size), Oficio (media size), Statement (140 x 216mm)
ISO A-series sizes (A0...A9)A4, A5, A6
ISO B-series sizes (B0...B9)B5
Photo paper sizes (imperial)4x6, 5x7 \
Borderless printing media sizes4x6, 2L, A4, B5, Hagaki card, L, Legal, Letter
Maximum ISO A-series paper sizeA4
DisplayLCD
Display diagonal2.4 \
Market positioningHome & office
Standard interfacesEthernet, USB 2.0, Wireless LAN
USB 2.0 ports quantity2
Wi-Fi standards802.11b, 802.11g, Wi-Fi 4 (802.11n)
Security algorithms802.1x RADIUS, EAP-TTLS, LEAP, MD5, PEAP, SSL/TLS
Supported network protocols (IPv4)TCP/IP, AppleTalk, TCP UDP
Supported network protocols (IPv6)TCP/IP
Internal memory256 MB
Processor frequency330 MHz
Sound pressure level (copying)49 dB
AC input voltage100 - 240 V
AC input frequency50 - 60 Hz
Power consumption (average operating)32 W
Package weight11960 g
Mac operating systems supportedMac OS X 10.4 Tiger, Mac OS X 10.5 Leopard, Mac OS X 10.6 Snow Leopard, Mac OS X 10.7 Lion
Linux operating systems supportedRedHat EL Linux 4.0 U5, RedHat EL Linux 4.0 U6, RedHat EL Linux 4.0 U7, RedHat EL Linux 5.0, Solaris 10 U4, Solaris 10 U5, Ubuntu 10.04, Ubuntu 9.04, Ubuntu 9.10
Server operating systems supportedWindows Server 2003, Windows Server 2003 x64, Windows Server 2008, Windows Server 2008 R2, Windows Server 2008 x64
Windows operating systems supportedWindows 7 Home Premium, Windows 7 Home Premium x64, Windows 7 Professional, Windows 7 Professional x64, Windows 7 Starter, Windows 7 Starter x64, Windows 7 Ultimate, Windows 7 Ultimate x64, Windows Vista Business, Windows Vista Business x64, Windows Vista Home Basic, Windows Vista Home Basic x64, Windows Vista Home Premium, Windows Vista Home Premium x64, Windows Vista Ultimate, Windows Vista Ultimate x64, Windows XP Home, Windows XP Home x64, Windows XP Professional, Windows XP Professional x64
Operating temperature (T-T)16 - 32 °C
Operating relative humidity (H-H)8 - 80 %
Sustainability certificatesENERGY STAR
CertificationCSA, c-UL-us, ICES Class B, Executive Order 132221, CE Class B, CB IEC 60950 IEC 60825-1, GS (TÜV), SEMKO, C-tick mark Class B, V85, CCC Class B, BSMI Class B, METI(PSE), VCCI Class B, FCC Class B, UL 60950 3rd Edition, CCIB
Weight and Dimensions IconWeight and Dimensions
Weight9090 g
