Ordering a maintenance kit
When 80 Routine maintenance needed appears, order a maintenance kit. The maintenance kit contains all
the items necessary to replace the pick rollers, the charge roll, the transfer roller, and the fuser.
Notes:
• Using certain types of paper may require more frequent replacement of the maintenance kit. The charge roll,
fuser, pick rollers, and transfer roller can also be individually ordered and replaced as necessary.
• To check the fuser type (T1 or T2) installed in the printer, remove the print cartridge to view the label on the
fuser.
Part name Part number
Maintenance kit 40X4723 (100 V T1 fuser)
40X4724 (110 V T1 fuser)
40X4765 (220 V T1 fuser)
40X4766 (100 V T2 fuser)
40X4767 (110 V T2 fuser)
40X4768 (220 V T2 fuser)
Ordering charge rolls
When toner fog or background shading appears on printed pages, order replacement charge rolls.
Part name Part number
Charge roll assembly 40X5852
Ordering a fuser
To check the fuser type (T1 or T2) installed in the printer, remove the print cartridge to view the label on the fuser.
Part name Part number
T1 fuser 40X1870 (100 V)
40X4418 (110 V)
40X1871 (220 V)
T2 fuser 40X1872 (100 V)
40X1873 (110 V)
40X1874 (220 V)
Ordering a fuser wiper
When Replace wiper appears on the display, order a fuser wiper.
Part name Part number
Fuser wiper 40X4417
Maintaining the printer
172
