Attach cables
Step 13: Attach cables
You can attach your printer to a network or locally (directly to a
computer).
Network printing You can attach your printer to a network using standard network
cables.
A 10BaseT/100BaseTX Fast Ethernet port is standard on the
Lexmark W820n and Lexmark W820dn. You can add a Token-Ring or
10Base2 Ethernet port to any printer model by installing an optional
MarkNet internal print server.
To attach the printer to a network:
1 Make sure the printer is turned off and unplugged.
2 Connect the printer to a LAN drop or hub using standard
cabling that is compatible with your network.
The printer automatically adjusts itself for the network speed.
— Token-Ring, Ethernet 10BaseT, or Ethernet 100BaseTX
networks (Category 5) use an RJ-45 connector.
