27
Install memory and option cards
Warning! Support the bottom of the
system board when installing a card.
6 While holding the system board
from the bottom, push the
memory card firmly into the
connector until the latches on
either end of the connector snap
into place.
It may require some force to fully
seat the card.
Make sure each latch fits over the
notch on the end of the card.
7 Repeat steps 4 through 6 to install
other memory cards.
Notch
Notch
What do I do next?
Task Go to page…
Installing an optional firmware card 28
Installing option cards 30
Reinstalling the system board 33
jp_setup.book Page 27 Friday, February 16, 2001 7:42 AM
