531
9-1. Specifications
9
Vehicle specifications
IS350/300/200t_U (OM53D18U)
■ Spark plug
Cooling system
Capacity
IS350/IS300 10.1 qt. (9.6 L, 8.4 Imp. qt.)
IS200t
Engine
8.2 qt. (7.8 L, 6.9 Imp. qt.)
Intercooler
3.2 qt. (3.0 L, 2.6 Imp. qt.)
Coolant type
Use either of the following:
• “Toyota Super Long Life Coolant”
• Similar high-quality ethylene glycol-based non-
silicate, non-amine, non-nitrite, and non-borate
coolant with long-life hybrid organic acid tech-
nology
Do not use plain water alone.
Ignition system
IS350/IS300 IS200t
Make DENSO FK20HBR11 NGK DILFR7K9G
Gap 0.043 in. (1.1 mm) 0.035 in. (0.9 mm)
■ Iridium-tipped spark plugs
Use only iridium-tipped spark plugs. Do not adjust the spark plug gap.
Electrical system
Battery
Open voltage at 68F
(20C):
12.6 12.8 V Fully charged
12.2
12.4 V Half charged
11.8
12.0 V Discharged
(Check the voltage 20 minutes after the engine and all
lights are turned off.)
Charging rates 5 A max.
