9-1. Specifications

Vehicle specifications

IS350/300/200t_U (OM53D18U)

: Minimum pedal clearance when depressed with a force of 112.4 lbf (500 N, 51.0 kgf)

while the engine is running.

: Parking brake pedal travel when depressed with a force of 67.4 lbf (300 N, 30.6 kgf)

Brakes

Pedal clearance*

2WD 4.2 in. (107 mm) Min.

AWD 4.7 in. (118 mm) Min.

Pedal free play 0.04 — 0.08 in. (1.0 — 2.0 mm)

Brake pad wear limit 0.04 in. (1.0 mm)

Parking brake lining wear limit 0.04 in. (1.0 mm)

Parking brake pedal travel*

7  10 clicks

Fluid type SAE J1703 or FMVSS No. 116 DOT 3

Steering

Free play Less than 1.2 in. (30 mm)
