Description
10
GA 05.139/1.02 - 06/99
Fig. 6 Dimensional drawing and standard fixing of the MAG.DRIVE; dimensions in mm
ST ART
ST OP
Com
Status
Main
X7
Fuses TMS
MAG.DRIVE 2000
Each Fuse 4
A
19“ installation frame
4 x M3 screws
455
113
196
128
135
27
max. 115
122.4
198
Ø 3.3
Each Fuse 4 A
straight plugs
bended plugs
