Maintenance
49
GA 05.139/1.02 - 06/99
Fig. 38 Sealing the MAG tightly with the metal seal kit
bolts
collar flange
retaining ring
blank flange
Centering ring
with O-ring
desiccant
nuts
sealing disc
screwed sealing plug for
purge gas connector
cap
polyethylene bag
with cable tie
desiccant
centering ring with O-ring
blank flange
clamping ring
