APPENDIX
120
APPENDIX
**
RReeaall ddaattaa mmaappppiinngg 11
00 : Step 0
A : Step 10 (Set ID 10)
F : Step 15 (Set ID 15)
10 : Step 16 (Set ID 16)
64: Step 100
6E : Step 110
73 : Step 115
74 : Step 116
C7: Step 199
FE : Step 254
FF : Step 255
**
RReeaall ddaattaa mmaappppiinngg 22
00 :-40
01 :-39
02 :-38
28 : 0
4E : +38
4F : +39
50 : +40
2200..TTuunnee CCoommmmaanndd ((CCoommmmaanndd:: mm aa))
G Select channel to following physical number.
Transmission
Data00 : High channel data
Data01 : Low channel data
ex. No. 47 -> 00 2F (2FH)
No. 394 -> 01 88 (188H),
DTV No. 0 -> Don’t care
Data020x00 : ATV Main
0x10 : DTV Main
Channel data range
Analogue - Min: 00 ~ Max: 63 (0~99)
Digital - Min: 00 ~ Max: 3E7 (0~999)
[m][a][ ][Set ID][ ][Data0][ ][Data1][ ][Data2][Cr]
Ack
[a][ ][Set ID][ ][OK/NG][Data][x]
Data Min: 00 ~ Max: FF
2211.. CChhaannnneell AAdddd//SSkkiipp((CCoommmmaanndd:: mm bb))
G To set skip status for the current Programme.
Transmission
Data 00 : Skip 01 : Add
[m][b][ ][Set ID][ ][Data][Cr]
Ack
[b][ ][Set ID][ ][OK/NG][Data][x]
1177.. PPoowweerr SSaavviinngg ((PPllaassmmaa TTVV oonnllyy))
((CCoommmmaanndd:: jj qq ))
G To reduce the power consumption of the TV. You can also
adjust Low Power in OPTION menu.
Transmission
Data Min :00 ~ Max :04 (*transmit by hexadecimal code)
[j][q][ ][Set ID][ ][Data][Cr]
Ack
[q][ ][Set ID][ ][OK/NG][Data][x]
1188.. AAuuttoo CCoonnffiigguurree((CCoommmmaanndd:: jj uu ))
G To adjust picture position and minimize image shaking
automatically. It works only in RGB (PC) mode.
Transmission
Data 01 : To set
[j][u][ ][Set ID][ ][Data][Cr]
Ack
[u][ ][Set ID][ ][OK/NG][Data][x]
1199.. EEqquuaalliizzee(( CCoommmmaanndd:: jj vv))
G To adjust equalize.
Transmission
MSB LSB
0
[j][v][ ][Set ID][ ][Data][Cr]
0 0 0 0 0 0 0
Frequency Data
Ack
[v][ ][Set ID][ ][OK/NG][Data][x]
Frequency
80Hz
00000 ~10 010
220Hz
470Hz
1KHz
2.2KHz
4.7KHz
12KHz
765
000
001
010
011
100
101
110
43210
