Front Panel and Rear Panel
Do not touch the inner pins of the jacks on the rear
panel. Electrostatic discharge may cause permanent
damage to the unit.
AUDIO
L
R
AV2 IN AV1 IN
S-VIDEO OUT connector
FM Antenna connector
AM Loop Antenna connectors
SPEAKER connectors
Power Cord
MONITOR OUT connector
OPTICAL IN
connector
COMPONENT VIDEO OUT terminals
Connect to a TV with Y Pb Pr inputs.
AV1 AUDIO Input (L/R)/VIDEO IN Connectors
AV2 AUDIO Input
(L/R)/VIDEO IN
Connectors
TRANSMITTER
(DC 7V OUT)
Connector
OPEN/CLOSE button
TUNING(-/+)/SKIP(-/+)
buttons
Remote sensor
PHONES connector
VOLUME controller
STANDBY/ON
DISPLAY Window
STANDBY indicator
Lights red when the receiver
is in Standby mode (off).
DISC Tray
USB host
Connect to a USB port of
multimedia
(USB memory etc.)
FUNCTION/PLAY
Press and hold down this button about 3
seconds, then press repeatedly to select
other function.
MONO/STEREO/
PAUSE/STEP
STOP
