LG BE320-SD - Lamp Replacement Procedure

English
43
English
Appendices
Lamp Replacing Procedure:
1. Switch off the power to the projector by pressing the “POWER ”.
2. Allow the projector to cool down at least 45 minutes.
3. Disconnect the power cable.
4. Unscrew the one screw on the front cover. 
5. Push and slide the top cover  and then open the top cover. 
6. Remove the 2 screws from the lamp module  and pull up the lamp bar. 
7. Pull out the lamp module by force. 
8. Install the new lamp module by reversing the previous steps.
9. After replacing the lamp, turn on the power, and select the menu ->
[OPTIONS|Lamp Settings] ->[Clear Lamp Hours] to reset the lamp usage
hours. refer to page 33.
N
o
t
e
1
2
3
5
4
6
The screws on the
lamp cover and
the lamp cannot be
removed.
Do not touch the
glass area of the
lamp. Hand oil can
cause the lamp to
shatter. Use a dry
cloth to clean the
lamp module if it
was accidentally
touched.
