Appendices
Con gurations of Terminals
Terminal: RS232 Pin Assignments
Pin no.
Spec.
(from projector back)
1 GND
2 Received Data (RXD)
3 Transmitted Data (TXD)
4 GND
5 GND
6 GND
7 GND
8 GND
9 GND
12345
6789
