1-8
SPECIFICATIONS
• GENERAL
AC adapter
Dimensions (W x H x D)
Net Weight (Approx.)
Operating temperature
Operating humidity
Model: WA-12M12FU
Manufacturer: Asian Power Devices Inc.
Input: 120 V~, 50-60 Hz 0.5 A Max.
Output: 12 V 1 A
Approx. 270 mm x 43 mm x 195 mm
(10.62 x 1.69 x 7.68 Inches)
0.87 kg (1.92 lbs)
5
°C to 35 °C
5 % to 90 %
• OUTPUTS
HDMI OUT (video/audio) 19 pin (Type A, HDMI™ Connector)
DIGITAL AUDIO OUT (COAXIAL) - (Option) 0.5 V (p-p), 75 Ω, RCA jack x 1
• SYSTEM
Laser Semiconductor laser
wavelength 405 nm / 650 nm
Signal system Standard PAL/NTSC Color TV system
LAN port - (Option) Ethernet jack x 1, 10BASE-T / 100BASE-TX
Wireless LAN (internal antenna) - (Option) Integrated IEEE 802.11b/g/n (2.4 GHz bands)
wireless networking access
Bus Power Supply (USB) DC 5 V 500 mA
Note : Design and specifications are subject to change prior notice.
