LG BS254 Service Manual

Delta Elec. Inc. BS254 & BX254 & BX324 rev.06
Company Confidential LGE_______________________ Delta____________
5
2011/06/16
Do not look into a lens during projection. This damages your eyes.
2. Specifications
2-1. Summary Specifications
Model BS254 BX254 BX324
Display type TI DMD 0.55-inch SVGA TI DMD 0.55-inch XGA
Resolution SVGA 800x600 Native
XGA 1024x768 Native
Projection distance 1 meters ~ 10 meters
Projection screen size 36 to 243 inch (can overdrive 300”)
Projection lens Manual focus / Manual zoom
Zoom ratio 1.1
Vertical keystone
correction
+/- 15 degrees
Projection methods Front, Rear, Desktop/Ceiling (Rear, Front)
Data compatibility IBM PC or compatibles (VGA, SVGA, XGA, SXGA, UXGA), Mac
SDTV/EDTV/ HDTV 480i, 576i, 480p, 576p, 720p, 1080i, 1080p
Video compatibility NTSC, PAL , SECAM
H-Sync 15, 30 – 91.4 KHz
V-Sync 43 - 87 Hz
Safety certification FCC-B, UL, cUL, TUV, CB, CE, PCT, SASO, NOM, KC and CCC
Operation temperature 5° ~ 35°C
Dimensions 261 mm (W) x 78 mm (H) x 190 mm (D)
WEIGHT 4.1 lbs 4.0 lbs
AC Input AC Universal 100 ~ 240, Typical @ 110 VAC (100~240)/±10%
Power consumption
Typical 230W (standard mode);
Typical 205W (ECO mode)
Typical 300W (standard mode);
Typical 230W (ECO mode)
Stand By < 1 watts
Lamp
Normal Mode: 180W;
Eco Mode: 160W
Normal Mode: 240W;
Eco Mode: 180W
Audio speaker 1.5W mono speaker
PC RGB
Composite video (RCA X 1)
Video
S-Video (Mini-DIN)

LG BS254 Specifications

General

Projection distance	0.129 - 2 m
Projection technology	DLP
Contrast ratio (typical)	2100:1
Screen size compatibility	51 \
Projector native resolution	SVGA (800x600)
Resolution	1280 x 1024 pixels
Aspect ratio	4:3, 16:9
RS-232 ports	1
Dimensions (WxDxH)	260.9 x 186.4 x 71.3 mm
Power requirements	100-240V
Lamp power	180 W
Light source type	Lamp
Service life of light source	2000 h
Service life of light source (economic mode)	3000 h
Focus	Manual
Focal length range	- mm
RMS rated power	1.5 W
DVI port	No
Serial interface type	RS-232
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Component video (YPbPr/YCbCr) in	-
Ethernet LAN (RJ-45) ports	0
Power consumption (standby)	- W
Power consumption (typical)	205 W

Weight and Dimensions

Weight	1910 g
