10-3. Power & READY LED Blink Code Message
LED Error Messages
E RROR C ODE M ESSAGES
P OWER LED
B LINK ( GREEN )
T EMP LED
( RED )
L AMP LED B LINK
(ORANGE)
Over temperature OFF ON OFF
Thermal break status error 4 OFF OFF
Lamp error 5 OFF OFF
Fan1 error 6 OFF 1
Fan2 error 6 OFF 2
Fan3 error 6 OFF 3
Lamp door open 7 OFF OFF
DMD error 8 OFF OFF
Color wheel error 9 OFF OFF
In the event of an error, please disconnect the AC power cord and wait for one (1) minute
before restarting the projector. If the POWER or LAMP LED are still blinking or the over temp
LED is lit, contact your service center.

LG BS254 Specifications

General

Projection distance	0.129 - 2 m
Projection technology	DLP
Contrast ratio (typical)	2100:1
Screen size compatibility	51 \
Projector native resolution	SVGA (800x600)
Resolution	1280 x 1024 pixels
Aspect ratio	4:3, 16:9
RS-232 ports	1
Dimensions (WxDxH)	260.9 x 186.4 x 71.3 mm
Power requirements	100-240V
Lamp power	180 W
Light source type	Lamp
Service life of light source	2000 h
Service life of light source (economic mode)	3000 h
Focus	Manual
Focal length range	- mm
RMS rated power	1.5 W
DVI port	No
Serial interface type	RS-232
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Component video (YPbPr/YCbCr) in	-
Ethernet LAN (RJ-45) ports	0
Power consumption (standby)	- W
Power consumption (typical)	205 W

Weight and Dimensions

Weight	1910 g
