Delta Elec. Inc. BS254_BX254_BX324 rev.06
Company Confidential LG ______________________ Delta____________
84
2011/06/16
13. Spare part list
BS254 & BX254 & BX324 Spare Parts List
LG P/N P/N DESCRIPTION BS254
3392128903 TOP COVER PC 5VB BLK V
2 ACQ36734808
3392133803 TOP COVER PC 5VB BLK
3392132903 BTM COVER PC 5VB GRAY V V V
4 AGU36744603
3392130202 IO COVER PC 5VB BLK V V V
5 ACQ36744703
3392129001 FRONT COVER PC 5VB BLK V V V
6 ACQ36744803
3392133001 LAMP DOOR PC 5VB GRAY V V V
7 MCK42367502
3392124000 LENS CAP PC 94V0 TRANSPARENT V V V
8 MDJ42498304
3797697800 COLOR WHEEL MODULE V V V
9 EAL32377714
3622404311
DC FAN ASSY BUB04512HD-SM00 L70/25 45 S V V V
10 EAL32377713
3622609011 DC FAN ASSY AUB0612VHD-SM00 L70/25 60 S V V V
11 EBT61018001
5600601264 PWB ASSY MAIN BD J5P ULTRA-02 V
12 EBT61018101
5600601393 PWB ASSY MAIN BD J5P ULTRA-02-02 V
13 EBT61018201
5600601395 PWB ASSY MAIN BD J5P ULTRA-02-03 V
14 EBT61018301
5600601366 PWB ASSY POWER+BALLAST V V
15 EBT61018401
5600601363 PWB ASSY POWER+BALLAST
5600601241 PWB ASSY DMD BD J5P ULTRA-01 V V V
17
EBT61018601
5600601233 PWB ASSY LVPS BD V V V
18 EBT61018701
5600601265 PWB ASSY KEYPAD BD J5P ULTRA-02 V V V
19 EBT61018801
5600601239 PWB ASSY INDEX BD J5P ULTRA-01 V V V
20 EBT61018901
5600601238 PWB ASSY IR BD J5P ULTRA-01 V V V
21 EBT56810405
OPTICAL MODULE S450 SVGA REG ASSY V
22 EBT56810406
OPTICAL MODULE S450 XGA REG ASSY
OPTICAL MODULE S450 XGA REG ASSY
LAMP MODULE J5P ULTRA E19 180W ASSY V V
25 EBT43485104
LAMP MODULE J5P ULTRA E19 240W ASSY
