2-2. Views of Projector parts
I
TEM
L
ABEL
D
ESCRIPTION
1.
IR receiver Receiver for IR signal from remote control
2.
Lens cap Covers lens to protect when not in use
3.
Height-adjust button Push to release height adjuster
4.
Height adjuster Adjusts level of projector
5.
Lens Remove lens cap before use
6.
Zoom ring Enlarges the projected image
7.
Focus ring Focuses the projector image
8.
Function keys See Top view-on screen Display (OSD) buttons and LEDS
9.
Height adjuster Adjusts level of projector
Important:
Ventilation openings on the projector allow for good air circulation, which keeps the projector
lamp cool. Do not obstruct any of ventilation openings.
