LG BS254 Service Manual

Delta Elec. Inc. BS254_BX254_BX324 rev.06
Company Confidential LG ______________________ Delta____________
80
2011/06/16
Control Command Structure
The command is structured by the Header code, command code, data code and end code.
Most of the commands are structured except some for the compatibility issue with other
projectors.
Header code Command code
Data code End code
HEX 7Eh Command Data 0Dh
ASCII ‘~’ Command Data
CR
Control Sequence
The projector may send a return code after it received a command. If the command isn’t
received correctly, the projector will not send the return code
Operation Command
The operation commands execute the basic operation setting of this projector.
Operation ASCII HEX
Power On ※
~ P N CR ※
7Eh 50h 4Eh 0Dh
Power Off ~ P F CR 7Eh 50h 46h 0Dh
Auto Image ~ A I CR 7Eh 41h 49h 0Dh
Lamp Hour Reset ~ R L CR 7Eh 52h 4Ch 0Dh
Input Select RGB ~ S R CR 7Eh 53h 52h 0Dh
Input Select Video ~ S V CR 7Eh 53h 56h 0Dh
Input Select S-Video ~ S S CR 7Eh 53h 53h 0Dh
※ Power On command will only word at system standby.
※ CR : Carriage Return.

LG BS254 Specifications

General

Projection distance	0.129 - 2 m
Projection technology	DLP
Contrast ratio (typical)	2100:1
Screen size compatibility	51 \
Projector native resolution	SVGA (800x600)
Resolution	1280 x 1024 pixels
Aspect ratio	4:3, 16:9
RS-232 ports	1
Dimensions (WxDxH)	260.9 x 186.4 x 71.3 mm
Power requirements	100-240V
Lamp power	180 W
Light source type	Lamp
Service life of light source	2000 h
Service life of light source (economic mode)	3000 h
Focus	Manual
Focal length range	- mm
RMS rated power	1.5 W
DVI port	No
Serial interface type	RS-232
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Component video (YPbPr/YCbCr) in	-
Ethernet LAN (RJ-45) ports	0
Power consumption (standby)	- W
Power consumption (typical)	205 W

Weight and Dimensions

Weight	1910 g
