Chapter 2. SPECIFICATIONS
2 - 3
Specifications
Item s
G3F-DA3I G6F-DA2I G3F-DA3V G6F-DA2V
I/O points 16 points
Digital input 16bit(data part :12bits)signed binary
Analog output
DC 4～20mA
(External load resistance less than 510Ω)
0～10 VDC
(External load
resistance :
2KΩ～1MΩ)
-10～10 VDC
(External load
resistance :
2KΩ～1MΩ)
Max. resolution 4
μ
A(1/4000) 2.5 mV(1/4000) 5 mV(1/4000)
Accuracy ± 0.5%［Full Scale］
Max. conversion speed
(ms/channel)
15ms/ 8 channels 10ms/ 4 channels 15ms/ 8 channels 10ms/ 4 channels
Max. absolute input DC 24mA 15 VDC
Analog output points 8 channels/1module 4 channels/1module 8 channels/1module 4 channels/1module
Isolation Between input terminals and the PLC: Photo-coupler isolation
Terminals connected
consumption
20-point terminal
block
18-point terminal
block
20-point terminal block
18-point terminal
block
+5VDC 70 mA 40 mA 600 mA 40 mA
+15VDC - 120 mA - 80 mA
Internal Current
Consumption
*1
-15VDC - 25 mA - 60 mA
Voltage DC21.6~26.4V
External Power
Supply
Current 220 mA
Weight 410 g 200 g 390 g 200 g
[Table 2.3] Performance Specifications
REMARK
*1 The capacity of the GM6-PAFB is +15VDC : 0.5A, -15VDC : 0.2A
and when it is used to several D/A converter module simultaneously, please consider each D/A
converter module to satisfy current consumption of it.
If it is used in the GM6 series or K200S series, please make sure to the GM6-PAFB of power supply
Module.
