Chapter 4. FUNCITION BLOCK
4 - 2
4.2 Function Blocks for Local
4.2.1 Module Write_ Array Type (G3F-DA3V,G3F-DA3I,G4F-DA 3V,G 4F-DA3I : DA3AWR,
G4F-DA2V,G4F-DA2I,G6F-DA2V,G6F-DA2I : DA2AWR)
Module write function block of the Array type is a program for the use in performing for every channel in
block and setting a digital value to be converted into a D/A conversion.
Function
Block
I/O Variable
Data
Type
Descri ptions
REQ BOOL Function Block Execution Request Area
-The execution of function block initialization is requested in this area.
-If the status connected with this area is satisfied on the program execution and 0 is changed to 1,
function block for the module is executed.
BASE USINT
Base Location Number Area
-The base No. on which D/A conversion module is mounted is written on this area.
-Setting range : G3F-DA3V,G3F-DA3I,G4F -DA3V,G4F-DA3I,G4F-DA2V,G4F-DA2I : 0 to 3
G6F-DA2V,G6F -DA2I : 0
SLOT USINT Slot Location Number Area
-The slot No. on which D/A conversion module is mounted is written on this area.
-Setting range: 0 to 7
Input
DATA INT
[Array]
*Note1
Input Data Type Specification Area
-Input digital data type for each channel is specified in this area.
-Setting range: 0 ~ 4000
DONE BOOL Function Block Execution Complete Area
- When function block has been completed with no error, 1 is written and until next execution, 1 is
continuing. When error occurs, 0 is written and operation come to stop.
G3F-DA3V/DA3I
G4F-DA3V/DA3I
G4F-DA2V/DA2I
G6F-DA2V/DA2I
Output
STAT USINT Error Code Display Area
- When error occurs during function block processing, the error code number is written.
- For error code, refer to section 4.4.
Remark
Note 1: Array number of data type means the whole number of channels and channel number.
Array number of G3F-DA3V/G3F-DA3I/G4F-DA3V/G4F-DA3I is 8 and array number of G4F-DA2V/G4F-DA2I
/G6F-DA2V/G6F-DA2I is 4.
REQ
BASE
SLOT
DATA
DA3AWR
STAT
DONE
REQ
BASE
SLOT
DATA
DA2AWR
STAT
DONE
