Chapter 2. SPECIFICATIONS
2 - 2
2.2 Performance Specifications
Table 2..2 and table 2.3 shows performance specification of D/A conversion module.
Specifications
Item s
G4F-DA3I G4F-DA2I G4F-DA3V G4F-DA2V
I/O points 16 points
Digital input 16bit(data part :12bits)signed binary
Analog output
DC 4
～
20mA
(External load resistance less than 510
Ω
)
-10
～
10 VDC
(External load resistance :2K
Ω～
1M
Ω
)
Max. resolution 4μA(1/4000) 5 mV(1/4000)
Accuracy ± 0.5%［Full Scale］
Max. conversion speed
(ms/channel)
15ms/ 8 channels 10ms/ 4 channels 15ms/ 8 channels 10ms/ 4 channels
Max. absolute input DC 24mA 15 VDC
Analog output points 8 channels/1module 4 channels/1module 8 channels/1module 4 channels/1module
Isolation Between input terminals and the PLC: Photo-coupler isolation
Terminals connected
consumption
20-point terminal block
Internal Current
Consumption
70mA 680mA 700mA 400mA
Voltage DC21.6~26.4V
External Power
Supply
Current 220mA
Weight 280 g 260 g 280 g 260 g
[Table 2.2] Performance Specifications
REMARK
1)
GM4-PA1A and GM4-PA2A - DC5V:4A, DC24V:0.7A
2) GM4-PA1B and GM4-PA2B - DC5V:3A, DC24V:0.5A
