D Sensor Error
Disconnect this BK housing, .
Is resistance value between p
ins 3 & 4 as below? (BO to B
O)
No
Yes
Yes
Reconnect
No
Yes
换D_Sensor
Test Point Result
Pin3 to
pin4
1.156 ~
141.5 ㏀
If the same situation appears,
replace main PCB
Otherwise, explain to the customer!
Reconnect CON8 & BK housing
and Power ON
Housing-A
Main PCB
BO
BO
D-Sensor
21
22
3
4
CON8
·
4
3
BO
BO
Wiring diagram
Is it displayed under picture?
Is the connection loose ?(CON8)
Power Off
Tip : To protect of MICOM
Yes
Pin21,22
Disconnect CON8.Is resistance
value between pins 21 & 22 of
CON8 as below? (BO to BO)
Test Point Result
Pin21 to Pin 22
6 ~ 300 ㏀
Reconnect
No
Pin3,4
- 37-
To Next Page
