CIRCUIT VOLTAGE CHART
1. ICs
2. CAPACITORS
Designator Description Specifi cation Pin Number Voltage Spec Real Value
IC100 IC,Microcontrollers R5F100GHAFB VDD: #48 VDD: 1.6 V ~ 5.5 V VDD: 3.36 V
IC101 IC,EEPROM M24C16-RMN6TP VCC: #8 VCC: 1.8 V ~ 5.5 V VCC: 3.2 V
IC102 IC,Serial Flash Memory MX25L8035EM2I-10G VCC: #8 VCC: 2.7 V ~ 3.6 V VCC: 3.2 V
IC103 IC,Voltage Detector AZ7027RTRE1 VCC: #1 VCC: 0 V ~ 15 V VCC: 3.2 V
IC200 IC,A/D Converter PCM1808
VCC: #3
VDD: #4
VCC: 4.5 V ~ 5.5 V
VDD: 2.7 V ~ 3.6 V
VCC: 5.12 V
VDD: 3.38 V
IC300 IC,DC,DC Converter SN1406035RGER
VIN1: #22
VIN2: #9
LX1: #20
LX2: #11
VIN1, VIN2, LX1, LX2: -0.3 V ~ 20 V
VIN1: 5.12 V
VIN2: 5.12 V
LX1: 5.03 V
LX2: 5.03 V
IC301, IC302, IC303, IC305, IC307 IC,Analog Switch BD2242G
VIN: #1
VOUT: #6
VIN: 2.8 V ~ 5.5 V
VOUT: 2.8 V ~ 5.5 V
VIN: 5.2 V
VOUT: 5.2 V
IC304, IC309, IC601 IC,DC,DC Converter MP1432 VIN: #7 VIN: 4.5 V ~ 45 V VIN: 25.2 V
IC501 IC,Video Processors MT8506ODAG
DVCC12_K
DVCC33_IO
DDRVCCIO1
AVDD33
AVDD12
AVDD12
DVCC12_K: 1.14 V ~ 1.26 V
DVCC33_IO: 3.15 V ~ 3.45 V
DDRVCCIO1: 1.425 V ~ 1.575 V
AVDD33: 3.15 V ~ 3.45 V
AVDD12: 1.14 V ~ 1.26 V
AVDD12_LDO: 1.14 V ~ 1.26 V
DVCC12_K: 1.194 V
DVCC33_IO: 3.194 V
DDRVCCIO1: 1.44 V
AVDD33: 3.19 V
AVDD12: 1.19 V
AVDD12_LDO: 1.19 V
IC503, IC504 IC,DDR3 SDRAM H5TQ1G63EFR-PBC
VDD:
VDDQ:
VDD: 1.425 V ~ 1.575 V
VDDQ: 1.425 V ~ 1.575 V
VDD: 1.44 V
VDDQ: 1.44 V
IC505 IC,NAND Flash Memory H27U4G8F2ETR-BC VCC: #12, #37 VCC: 2.7 V ~ 3.6 V VCC: 3.2 V
IC600 IC,Sound/Audio Processor PS9860
VDD_IO: #17, #52
VDD_CORE: #6, #25
VIN33_REG1: #34
VIN33_REG2: #66
VDD_PLL: #68
VDD_IO: 2.97 V ~ 3.63 V
VDD_CORE: 1.08 V ~ 1.32 V
VIN33_REG1: 2.97 V ~ 3.63 V
VIN33_REG2: 2.97 V ~ 3.63 V
VDD_PLL: 1.08 V ~ 1.32 V
VDD_IO: 3.2 V
VDD_CORE: 1.19 V
VIN33_REG1: 3.2 V
VIN33_REG2: 3.2 V
VDD_PLL: 1.19 V
IC7000, IC7001 IC,Audio Amplifi er TAS5612LADDVR
PVDD: #29, #30, #31, #36, #37, #38
GVDD: #1, #22
VDD: #2
PVDD: 12 V ~ 34 V
GVDD: 10.8 V ~ 13.2 V
VDD: 10.8 V ~ 13.2 V
PVDD: 25.2 V
GVDD: 12.4 V
VDD: 12.8 V
Location Number Specifi cation (V, mW)
Rating-20 % ( 80 V, 60 Hz) Rating+20 % ( 288 V, 60 Hz)
Voltage (V) Voltage (V)
C7003 330uF/35V (105/2000HR) 25.2 25.2
C7034 330uF/35V (105/2000HR) 25.2 25.2
C7038 330uF/35V (105/2000HR) 25.2 25.2
C7069 330uF/35V (105/2000HR) 25.2 25.2
