LG LRE3061ST Service Manual

-2-3-
GENERAL
B
Dual surface unit : Left Front
C
Warming Zone : Center Rear
A
To turn on a single surface unit (Right Front,
Right Rear, Left Rear)
1. Press ON/OFF pad for the desired element.
2. Press ( + / – ) pad to choose the desired setting.
B
To turn on a dual surface unit (Left Front)
1. Press ON/OFF pad
2. Press the SELECT pad as needed to select the desired burner size.
When first selected, 9” size is on. The light above the SELECT pad
indicates which size surface unit is on.
3. Press ( + / – ) pad to choose the desired setting.
Note:
• Each time a pad is pressed a beep will sound.
• The power level decreases or increases by 0.5 from 9.0 through 3.0. (by 0.2 from 3.0
through 1.0)
• Lo is the lowest power level available.
• “HS” will appear when the unit is hot to touch
C
To set the warming zone control
1. Press ON/OFF pad for the desired element.
2. Press ( + / – ) pad to choose the desired setting.
Note:
• Each time a pad is pressed a beep will sound.
• The controls for the warming zone allow for 5 different heat settings : Lo~Hi
• “HS” will appear when the unit is hot to touch.
1. SETTING THE CLOCK
2. START, CLEAR/OFF AND ON/OFF PAD
1. Touch START pad to start oven.
2. Touch CLEAR/OFF pad to cancel a program during cooking or
Erase during programming.
3. Touch ON/OFF pad to start or cancel the surface unit.
3. TO TURN ON/OFF THE OVEN LIGHT
The oven light automatically turns ON when the door is opened. The
oven light may also be manually turned ON or OFF by pressing the
OVEN LIGHT pad
Note: The oven light cannot be turned on if self-clean feature is active.
4. TIMER ON/OFF
To cancel timer at any time, touch TIMER ON/OFF pad.
Note:
1. If you press TIMER ON/OFF pad once, this allows you to select "minutes"
(for example: if you press “5” and “6”, it means 56 minutes)
2. If you press TIMER ON/OFF pad twice, this allows you to select "seconds"
(for example: if you press “5” and “6”, it means 56 seconds)
5. SETTING PAD: 6 types of category
1) CONVECTION AUTO CONVERSION
1. Press SETTING pad once
2. Press “1” pad for ENABLE
or “2” pad for DISABLE
3. Press START pad.
2) THERMOSTAT ADJUSTMENT
The oven temperature can be adjusted from -35°F (-19°C) to 35°F
(19°C).
Note: The thermostat adjustments made with this feature will just change Bake,
Convection Bake and Convection Roast temperature.
USING YOUR RANGE
CLEAR /OFF CLOCK Desired Time START
TIMER ON/
OFF
Desired time
TIMER ON/
OFF

LG LRE3061ST Specifications

General

Style	single oven, freestanding
Color	stainless steel
Total Capacity	6.3 cubic feet
Induction	no
Number of Oven Racks	2
Number of Oven Rack Positions	7
Interior Light	yes
Fuel	electric

Weight and Dimensions

Depth	28 inches
Height	47 7/16 inches
Width	30 inches
Net Weight	167 pounds
