PRODUCT DATA | 13

Product Data

Due to our policy of continuous product innovation, some specications may change without notication.

Model Number Nominal Tons

Compressor

Qty

Compressor(A)

Cool/Heat

Fan Qty ODU Fan (A) IDU Fan (A) MCA(A) MOP(A)

LS090HEV1 3/4 1 7.0/7.0 1 0.5 0.5 10 15

LS120HEV1 1 1 7.0/7.0 1 0.5 0.5 10 15

LS180HEV1 1-1/2 1 8.81/8.61 1 0.4 0.4 12 20

LS240HEV1 2 1 10.72/10.28 1 0.4 0.4 15 20

Mega Inverter and Mega 115V Outdoor Units

ELECTRICAL DATA

Table 4: 208-230V, 60Hz, 1-Phase Single-Zone Mega Inverter System Electrical Data Table.

Table 5: 115V, 60Hz, 1-Phase Single Zone Single-Zone Mega 115V System Electrical Data Table.

Model Number Nominal Tons

Compressor

Qty

Compressor(A)

Cool/Heat

Fan Qty ODU Fan(A) IDU Fan (A) MCA(A) MOP(A)

LS090HXV 3/4 1 10/10 1 0.4 0.5 13.5 20

LS120HXV 1 1 10/10 1 0.4 0.5 13.5 20

Voltage tolerance is ±10%.

Maximum allowable voltage unbalance is 2%.

MCA = Minimum Circuit Ampacity.

Maximum Overcurrent Protection (MOP) is calculated as follows: (Largest motor FLA x 2.25) + (Sum of

other motor FLA) rounded down to the nearest standard fuse size.

Voltage tolerance is ±10%.

Maximum allowable voltage unbalance is 2%.

MCA = Minimum Circuit Ampacity.

Maximum Overcurrent Protection (MOP) is calculated as follows: (Largest motor FLA x 2.25) + (Sum of

other motor FLA) rounded down to the nearest standard fuse size.

LG LS090HEV1 Engineering Manual
