LG LS090HEV1 Engineering Manual

PRODUCT DATA | 21
Product Data
Due to our policy of continuous product innovation, some specications may change without notication.
©
LG Electronics U.S.A., Inc., Englewood Cliffs, NJ. All rights reserved. “LG ” is a registered trademark of LG Corp.
INDOOR UNIT DIMENSIONS
LSN180HEV1, LSN240HEV1
Unit
Outline
Left Rear
Piping
Right Rear
Piping
Place a level on raised tab
Ø2-9/16
Ø2-9/16
18-1/8 22-3/8
8-11/16
12-1/8
7.24in(184mm)
7-1/4
6.14in(156mm)
6-3/16
9-13/16
2-9/16
1-13/16
2-1/16
40-9/16
12-13/16
9-13/16
5
4
2-1/16
1-13/16
Unit: Inch
R
eturn Air
G
rille
K
nockout Hole for Piping & Cable

LG LS090HEV1 Specifications

General

Brand	LG
Model	LS090HEV1
Category	Air Conditioner
Language	English
