12
6LQJOH=RQH+LJK(I¿FLHQF\6WDQGDUG([WHQGHG3LSHDQG0HJD:DOO0RXQW,QVWDOODWLRQ0DQXDO
Due to our policy of continuous product innovation, some specifications may change without notification.
©LG Electronics U.S.A., Inc., Englewood Cliffs, NJ. All rights reserved. “LG” is a registered trademark of LG Corp.
GENERAL DATA
SLQJOH =RQH 0HJD 8QLW HEV SSHFL¿FDWLRQV
Type Single Zone Mega (HEV) Inverter
System (Model IDU/ODU)
LS090HEV
(LSN090HEV/
LSU090HEV)
LS120HEV
(LSN120HEV/
LSU120HEV)
LS180HEV
(LSN180HEV/
LSU180HEV)
LS240HEV
(LSN240HEV/
LSU240HEV)
Nominal Cooling Capacity (Btu/h) 8,500 12,000 17,000 22,000
Cooling Power Input
1
(kW) 0.78 1.17 1.55 2.04
Nominal Heating Capacity (Btu/h) 9,000 12,000 19,000 22,000
Heating Power Input
1
(kW) 0.78 0.98 1.59 1.93
COP 3.19 3.00 3.19 3.00
EER 10.90 10.26 10.95 10.75
SEER 16.3 16.3 17.0 17.0
HSPF 8.3 8.5 8.7 8.5
Power Supply (V / Hz / Ø) 208-230/60/1
ODU Operating Range
Cooling (°F DB) 64-118
Heating (°F WB) 23-75
IDU Operating Range
Cooling (°F WB) 64-90
Heating (°F DB) 60-86
Indoor Temperature Setting Range
Cooling (°F) 65-86
Heating (°F) 61-86
Unit Data
Refrigerant Type
2
R410A
Refrigerant Control Capillary Tube
IDU Sound Pressure
3
± 3 dB(A) (H/M/L) 39/33/25 39/33/25 42/40/35 45/40/35
ODU Sound Pressure ± 3 dB(A) 47 47 51 53
Indoor Unit (Net/Shipping Weight lbs.) 16/21 20/25 28/30 28/34
Outdoor Unit (Net/Shipping Weight lbs.) 52/56 49/53 72/77 92/104
Power/Communication Cable
4
(No. x AWG) 4 x 18
Compressor
Compressor Type (Qty) Single Rotary (1) Single Rotary (1) Twin Rotary (1) Twin Rotary (1)
Fan
Indoor Type (Qty) Cross Flow (1)
Outdoor Type (Qty) Propeller (1)
Motor/Drive Brushless Digitally Controlled/Direct
Airflow Rate
Indoor - Max/H/M/L (CFM) 318/276/226/177 424/353/272/212 629/512/441/353 689/600/494/388
Outdoor - Max (CFM) 953 953 1,342 1,766
Piping
Liquid Line (in, OD) 1/4 1/4 1/4 1/4
Vapor Line (in, OD) 3/8 3/8 1/2 5/8
Condensation Line (OD | ID) 27/32 | 5/8 27/32 | 5/8 27/32 | 5/8 27/32 | 5/8
Additional Refrigerant Charge (oz/ft) 0.22 0.22 0.33 0.33
Pipe Length
5
(ft) (Min./Max.) 9.8/49.2 9.8/49.2 9.8/65.6 9.8/65.6
Piping Length (no add’l refrigerant, ft)
5
24.6 24.6 24.6 24.6
Max Elevation Difference (ft) 22.9 22.9 32.8 32.8
Table 4: Single =one Mega Unit (HEV) Speci¿cations
EEV: Electronic Expansion Valve IDU: Indoor Unit ODU: Outdoor Unit
1
Power Input is rated at high speed.
2
Take appropriate actions at the end of HVAC equipment life to recover, recycle, reclaim or destroy
R410A refrigerant according to applicable regulations (40 CFR Part 82, Subpart F) under section 608
of CAA.
3
Sound Pressure levels are tested in an anechoic chamber under ISO Standard 1996.
4
Power/communication cables from the outdoor unit to the indoor unit to be minimum 18 AWG, 4-con-
ductor, stranded, shielded or unshielded (if shielded, it must be grounded to the chassis at the outdoor
unit only) and must comply with applicable and national code.
5
Piping lengths are equivalent.
Power wiring to the outdoor unit is field supplied, solid or stranded, and must comply with the applicable
local and national codes. This unit comes with a dry helium charge.
This data is rated 0 ft above sea level with 24.6 of refrigerant line per indoor unit and a 0 ft level
difference outdoor and indoor units.
Cooling capacity rating obtained with air entering the indoor unit at 80ºF dry bulb (DB) and 67ºF wet
bulb (WB) and outdoor ambient conditions of 95ºF dry bulb (DB) and 75ºF wet bulb (WB).
Heating capacity rating obtained with air entering the indoor unit at 70ºF dry bulb (DB) and 59ºF wet
bulb (WB) and outdoor ambient conditions of 47ºF dry bulb (DB) and 43ºF wet bulb (WB).
