9
Product Data
Due to our policy of continuous product innovation, some specifications may change without notification.
©LG Electronics U.S.A., Inc., Englewood Cliffs, NJ. All rights reserved. “LG” is a registered trademark of LG Corp.
GENERAL DATA
SLQJOH =RQH HLJK EI¿FLHQF\ 8QLW SSHFL¿FDWLRQV
Type 6LQJOH=RQH+LJK(IÀFLHQF\8QLWV
System Model Number (IDU/ODU)
LS091HSV3
(LSN091HSV3/
LSU091HSV3)
LS121HSV3
(LSN121HSV3/
LSU121HSV3)
LS181HSV3
(LSN181HSV3/
LSU181HSV3)
LS240HSV3
(LSN240HSV3/
LSU240HSV3)
Nominal Cooling Capacity (Btu/h) 9,000 11,200 18,200 22,000
Cooling Power Input
1
(kW) 0.67 0.89 1.4 1.7
Nominal Heating Capacity (Btu/h)
1
10,800 13,300 22,000 27,600
Heating Power Input
1
(kW) 0.70 1.0 1.7 2.3
COP 4.53 3.90 3.66 3.4
EER 13.3 12.5 12.6 12.5
SEER 21.5 21.5 20.5 20.0
HSPF 11.0 11.0 9.7 10.2
Power Supply (V/Hz/Ø) 208-230/60/1
Outdoor Unit Operating Range
2
Cooling (°F DB) 14-118
Heating (°F WB) -4-75
Indoor Unit Operating Range
2
Cooling (°F) 64-90
Heating (°F) 60-86
Unit Data
Refrigerant Type
3
R410A
Refrigerant Control EEV
IDU Sound Pressure
4
dB(A) (H/M/L) 38/33/24 39/33/24 45/40/35 46/43/39
ODU Sound Pressure
4
dB(A) 45 45 53 54
Power/Communication Cable
5
(No. x AWG) 4 x 18
IDU Net/Shipping Weight (lbs) 23/28 23/28 32/41 36/42
ODU Net/Shipping Weight (lbs) 75/79 75/79 123/131 128/137
Compressor
Compressor Type (Qty) Rotary (1) Rotary (1) Twin Rotary (1) Twin Rotary (1)
Fan
IDU Type (Qty) Cross Flow (1)
ODU Type (Qty) Propeller (1)
Motor/Drive Brushless Digitally Controlled/Direct
Airflow Rate
IDU Max/H/M/L (CFM) 388/335/272/212 423/353/272/212 735/622/509/399 883/742/629/424
ODU Max (CFM) 1,165 1,165 2,119 2,119
Piping
Liquid Line (in, OD) 1/4 1/4 3/8 3/8
Vapor Line (in, OD) 3/8 3/8 5/8 5/8
Condensation Line (OD, ID) 27/32, 5/8 27/32, 5/8 27/32, 5/8 27/32, 5/8
Additional Refrigerant Charge (oz/ft) 0.22 0.22 0.38 0.38
Pipe Length
6
(ft) (Min./Max.) 6.6/65.6 6.6/65.6 9.8/98.4 9.8/98.4
Piping Length
6
(no add’l refrigerant, ft) 41.0 41.0 24.6 24.6
Max Elevation Difference (ft) 32.8 32.8 49.2 49.2
Table 1: Single =one High Ef¿ciency Unit Speci¿cations
EEV: Electronic Expansion Valve IDU: Indoor Unit ODU: Outdoor Unit
1
Power Input is rated at high speed.
2
Low Ambient Wind Baffle Kit allows operation down to 0°F in cooling mode.
3
Take appropriate actions at the end of HVAC equipment life to recover, recycle, reclaim or destroy R410A
refrigerant according to applicable regulations (40 CFR Part 82, Subpart F) under section 608 of CAA.
4
Sound Pressure levels are tested in an anechoic chamber under ISO Standard 1996.
5
Power/communication cables from the outdoor unit to the indoor unit to be minimum 18 AWG, 4-conduc-
tor, stranded, shielded or unshielded (if shielded, it must be grounded to the chassis at the outdoor unit
only) and must comply with applicable and national code.
6
Piping lengths are equivalent.
Power wiring to the outdoor unit is field supplied, solid or stranded, and must comply with the applicable
local and national codes.
This unit comes with a dry helium charge.
This data is rated 0 ft above sea level with 24.6 of refrigerant line per indoor unit and a 0 ft level
difference outdoor and indoor units.
Cooling capacity rating obtained with air entering the indoor unit at 80ºF dry bulb (DB) and 67ºF wet bulb
(WB) and outdoor ambient conditions of 95ºF dry bulb (DB) and 75ºF wet bulb (WB).
Heating capacity rating obtained with air entering the indoor unit at 70ºF dry bulb (DB) and 59ºF wet bulb
(WB) and outdoor ambient conditions of 47ºF dry bulb (DB) and 43ºF wet bulb (WB).
