LG LS090HEV1 Installation Manual

15
Product Data
Due to our policy of continuous product innovation, some specifications may change without notification.
©LG Electronics U.S.A., Inc., Englewood Cliffs, NJ. All rights reserved. “LG” is a registered trademark of LG Corp.
GENERAL DATA
Model Number Nom. Tons
Compressor
Qty
Compressor (A)
Cool/Heat
Fan Qty ODU Fan (A) IDU Fan (A) MCA (A) MOP (A)
LSU091HSV3 3/4 1 8.7/8.7 1 0.40 0.4 10 15
LSU121HSV3 1 1 8.7/8.7 1 0.40 0.4 10 15
LSU181HSV3 1-1/2 1 15.4/15.4 1 0.25 0.4 19 25
LSU240HSV3 1-3/4 1 15.4/15.4 1 0.25 0.5 19 25
Table 7: Single =one High Ef¿ciency Indoor Unit Electrical Data
Model Number Nom. Tons
Compressor
Qty
Compressor (A)
Cool/Heat
Fan Qty ODU Fan (A) IDU Fan (A) MCA (A) MOP (A)
LSU307HV3 2-1/2 1 15.4/15.4 1 0.25 0.5 19 25
LSU360HV3 2-3/4 1 15.4/15.4 1 0.25 0.5 19 25
Table 8: Single Zone Standard Indoor Unit Electrical Data
Model Number Nom. Tons
Compressor
Qty
Compressor
(A) Cool/Heat
Fan Qty ODU Fan (A) IDU Fan (A) MCA (A) MOP (A)
LSU240HLV 1-3/4 1 17.3/17.3 1 0.25 0.5 23 35
LSU300HLV 2-1/2 1 17.3/17.3 1 0.25 0.5 23 35
LSU360HLV 2-3/4 1 17.3/17.3 1 0.25 0.5 23 35
Table 9: Single Zone Extended Pipe Indoor Unit Electrical Data
EOHFWULFDO
Unit Model Nos. Nom. Tons
Compressor
Qty
Compressor
(A) Cool/Heat
Fan Qty ODU Fan (A) IDU Fan (A) MCA (A) MOP (A)
LSU090HEV 3/4 1 6.8/6.8 1 0.5 0.5 9 15
LSU120HEV 1 1 6.8/6.8 1 0.5 0.5 9 15
LSU180HEV 1-1/2 1 8.68/9.28 1 0.4 0.4 12 20
LSU240HEV 2 1 10.8/9.6 1 0.48 0.48 14 20
Table 10: 208-230V, 60Hz, 1-Phase Single Zone Mega (HEV) Indoor Unit Electrical Data
Table 11: 208-230V, 60Hz, 1-Phase Single Zone Mega (HEV1) Indoor Unit Electrical Data
Unit Model Nos. Nom. Tons
Compressor
Qty
Compressor
(A) Cool/Heat
Fan Qty ODU Fan (A) IDU Fan (A) MCA (A) MOP (A)
LSU090HXV 3/4 1 10/10 1 0.4 0.5 13.5 20
LSU120HXV 1 1 10/10 1 0.4 0.5 13.5 20
Voltage tolerance is ±10%.
Maximum allowable voltage unbalance is 2%.
MSC = Maximum Starting Current.
MCA = Minimum Circuit Ampacity.
Maximum Overcurrent Protection (MOP) is calculated as follows: (Largest motor FLA x 2.25) + (Sum of
other motor FLA) rounded down to the nearest standard fuse size.
Table 12: 115V, 60Hz, 1-Phase Single Zone Mega 115V Indoor Unit Electrical Data
Unit Model Nos. Nom. Tons
Compressor
Qty
Compressor
(A) Cool/Heat
Fan Qty ODU Fan (A) IDU Fan (A) MCA (A) MOP (A)
LSU090HEV1 3/4 1 7.0/7.0 1 0.5 0.5 10 15
LSU120HEV1 1 1 7.0/7.0 1 0.5 0.5 10 15
LSU180HEV1 1-1/2 1 8.81/8.61 1 0.4 0.4 12 20
LSU240HEV1 2 1 10.72/10.28 1 0.4 0.4 15 20
