CONNECTING DEVICES
HDMI to DVI Connection
Using an HDMI to DVI cable, connect
the projector's HDMI IN port to the DVI
OUT port.
To output audio, use an audio cable for
connection.
Press the INPUT button on the remote
control to select HDMI. You can connect
with any HDMI input port.
DVI OUT
AUDIO OUT
AV Connection
Connect the output ports of an external
device and the AV IN ports of the
projector using an AV cable. Press the
INPUT button on the remote control to
select AV.
Check whether cables of the same color
are connected properly.
$9287
/HIW 5LJKW
$8',2287
YELLOW
YELLOW
YELLOW
WHITE WHITE
WHITE
RED RED
RED
* Optional
Extras
* Accessories
* Optional
Extras
(Audio)
* Optional
Extras
(Video)
