Chapter 1 4
Optics-Conceptual Drawing
Mirror
Aspherical
Aspherical
Lamp Housing
Lens Assembly (3680V00116H)
Light Tunnel
Color WheelLens-C1
Osram Lamp (6912B22006E)
FAN (5900V03002K)
Heatsink
DMD (0.55 inch)
Lens-C2
DMD PCB
Thermal PCB (6871VSN257R)
