Chapter 3 16
Disassemble Power Outlet Set
1. Remove the screw from the bottom of power wires and unplug the connector.
2. Then lift up the power outlet set.
3. Remove the power outlet from the Middle cover
01635-A08
01635-705
01635-A08
01635-705
