LG RD-JS31 - Disassemble Power Board Assembly

17 Chapter 3
1. Unplug all the wires on the board (Power Board PIN location of connectors pls refer to
Chapter 5 )
2. Unscrew five screws on Power Board.
3. Then remove Power Board Assembly.
4. Remove the others from Power Board Assembly
Disassemble Power Board Assembly
P6134-7001-00
P6135-7000-00
P1635-052
c
d
b
e
a
02595-0014-00
401635-361 *5
P1684-0007
3110V00321H
6871VPM998C
