9 Chapter 3
1. Loosen two screws of Lamp Cover
2. Remove Lamp Cover
3. Loosen two screws of Lamp Module .
4. Grasp the lamp handle and pull out Lamp Module
Disassemble Lamp Module
Note:Unplug all the cord before disassembling the Projector.
P2034-454
01635-B77*2
P6184-0002
3580V00094K
3110V00321H
