11 Chapter 3
Disassemble Front Fan
1. Then life up the fan set directly .
1. Dispatch the top cover
2. Remove the FFC cable and main board mylar
Disassemble Top Cover
P6144-0002
P6134-7000-00
02591-0014-00
P6145-0002
3110V00320N
5900V03002L
