Chapter 3 10
1. Remove 3 screws of IO cover.
2. Separate all parts individually
Disassemble IO Cover
1. Remove the 2 screws on middle cover
2. Remove the 2 screws on botton cover
01635-D21*2
01635-367*2
3720V00206E
