SPECIFICATIONS
• GENERAL
Power consumption Refer to the main label on the unit.
AC adapter Model: DA-50F25
Manufacturer : Asian Power Devices Inc.
Input: 100 - 240 V ~ 50 - 60 Hz
Output: 25 V 2 A
Dimensions (W x H x D) Approx. 1060.0 mm x 57.0 mm x 119.0 mm (with foot)
(41.7 inch x 2.2 inch x 4.7 inch)
Operating temperature 5 °C to 35 °C (41 °F to 95 °F)
Operating humidity 5 % to 90 %
Bus Power Supply (USB) 5 V 500 mA
Available Digital Input Audio Sampling Frequency 32 kHz, 44.1 kHz, 48 kHz, 88.2 kHz, 96 kHz
Available Digital Input Audio format Dolby Atmos, Dolby Audio, DTS:X, DTS-HD, PCM
• INPUT/OUTPUT
OPTICAL IN 3 V (p-p), Optical jack x 1
HDMI IN 19 Pin (Type A, HDMI™ connector) x 1
HDMI OUT 19 Pin (Type A, HDMI™ connector) x 1
1080p, 1080i, 720p, 576p, 480p
2160p@24/25/30 Hz 4:4:4
2160p@60/50 Hz 4:2:0
4
K Sources dependent on HDCP 2.2 are supported at 4K resolutions.
• AMPLIFIER (RMS Output)
Total 440 W RMS
Front 50 W RMS x 2 (4 Ω at 1 kHz, THD 10 %)
Center 40 W RMS (4 Ω at 1 kHz, THD 10 %)
Top 40 W RMS x 2 (4 Ω at 1 kHz, THD 10 %)
Subwoofer 220 W RMS (3 Ω at 80 Hz, THD 10 %)
• WIRELESS SUBWOOFER
Power requirements Refer to the main label on the subwoofer.
Power consumption Refer to the main label on the subwoofer.
Type 1 Way 1 Speaker
Impedance 3 Ω
Rated Input Power 220 W RMS
Max. Input Power 440 W RMS
Dimensions (W x H x D) Approx. 221.0 mm x 390.0 mm x 312.8 mm
(8.7 inch x 15.4 inch x 12.3 inch)
• SYSTEM
Wireless LAN (Internal antenna) 802.11a/b/g/n Wi-Fi networks
SPK8-S (SPK8-S, S78S1-S), Sold Separately
• WIRELESS RECEIVER
Power requirements Refer to the main label on the wireless receiver.
Power consumption Refer to the main label on the wireless receiver.
Rear 70 W RMS x 2 (3 Ω at 1 kHz, THD 10 %)
Dimensions (W x H x D) Approx. 60.0 mm x 220.0 mm x 175.0 mm
(2.4 inch x 8.7 inch x 6.9 inch)
• REAR SPEAKERS (Each)
Type 1 Way 1 Speaker
Impedance 3 Ω
Rated Input Power 70 W RMS
Max. Input Power 140 W RMS
Dimensions (W x H x D) Approx. 100.0 mm x 140.0 mm x 100.0 mm
(3.9 inch x 5.5 inch x 3.9 inch)
• Designs and specifications are subject to change without prior notice.

LG SN8YG Specifications

General

Audio decoders	DTS Digital Surround, DTS Virtual:X, DTS-HD HR, DTS-HD Master Audio, DTS:X, Dolby Atmos, Dolby Digital, Dolby Digital Plus, Dolby TrueHD
Equalizer modes	Bass Blast, Bass Blast+, Standart
RMS rated power	440 W
Audio output channels	3.1.2 channels
Audio Return Channel (ARC)	Yes
Soundbar speaker RMS power	220 W
Subwoofer type	Active subwoofer
Subwoofer connectivity	Wireless
Ethernet LAN	No
HDCP version	2.2
Bluetooth version	4.2
Connectivity technology	Wired & Wireless
Digital audio optical out	1
FM radio	-
Display type	LCD
Product color	Black
Virtual assistant	Google Assistant
Audio formats supported	AAC, AAC+, FLAC, LPCM, MP3, OGG, WAV, WMA
Network streaming services supported	Chromecast
Mobile operating systems supported	Android, iOS
Cables included	Optical
Number of products included	1 pc(s)
Remote control battery type	AAA
Number of remote control batteries	4
Power source	AC
Soundbar power consumption	39.4 W
Power consumption (standby)	0.5 W
Subwoofer power consumption	36 W

Weight and Dimensions

Depth	119 mm
Width	1060 mm
Height	57 mm
Soundbar weight	4400 g
Subwoofer depth	312.8 mm
Subwoofer width	221 mm
Subwoofer height	390 mm
Subwoofer weight	7800 g
