4-2
Copyright © 2020 LG Electronics Inc. All rights reserved.
Only for training and service purposes.
2P, 3.96mm
ST, Non Lock , SMD
26P, 0.5mm
ST, Non Lock SMD
Wireless
2P, 3.96mm
ST, Non Lock SMD
Power
WIRING DIAGRAM
