1-5
Copyright © 2020 LG Electronics Inc. All rights reserved.
Only for training and service purposes.
NAME OF EACH COMPONENT
Front panel
(Standby)
- Switches the unit ON or OFF.
F (Function)
- Select the function and input source by pressing F repeatedly.
Input source / Function Display
Wi-Fi Wi-Fi
Bluetooth BT
Optical, ARC, LG Sound Sync (Wired) LG TV
HDMI IN HDMI
USB USB
Note: You can use Bluetooth function after making Wi-Fi network connection by using Google Home app.
+/− (Volume)
- Adjusts volume level.
- Starts playback. / Pauses playback.
(Mic mute)
- Disables the detect voice recognition by pressing . All the Google Assistant LED turns amber and
“The mic is muted.” is heard.
To cancel it, press again. Google Assistant LED turns off and “The mic is back on.” is heard.
- Enables Google Assistant to receive your voice commands .
To cancel it, press again.
Microphone
Remote sensor
1
2
3
