Only for training and service purposes.

2-122-11

• Main unit parts list

S AL LOCA. NO. PART NO. DESCRIPTION SPECIFICATION REMARKS

ASSEMBLY PARTS

A41 AAX76827604 Board Assembly HOME SM8YG TOP case+Touch PCB

A42 ABQ76920209 Case Assembly SM8YG BK Spray Case Bottom Ass

A43

EBR31299901 PCB Assembly SN8YG Front LED SVC Assy

A46

EBR30556301 PCB Assembly SN8YG MAIN SVC Assy

A47 EBT66439601 LFS Total PCB Assembly SN8YG AMP LFS total -

A51 EAT64454802 Module,Wiﬁ Bluetooth Module TWCM-K505D MT7668_Brazil 3.135

A51 EAT64454801 Module,Wiﬁ Bluetooth Module TWCM-K505D MT7668 3.135VTO3.6V

A54 EAT63117401 Module,RF Full Module(RxTx) WL1NB6(TWBI-H002D) 0DBM 0DB 0%

A54 EAT63117404 Module,RF Full Module(RxTx) WL1NB6_ 0DBM 0DB 0% 0A 0A 0DB

A80C ABQ77060902 Case Assembly SL8 Chamber Center

A80L ABQ77100402 Case Assembly SL8 Add EVA Chamber Top Front

A80R ABQ77100502 Case Assembly SL8 Add EVA Chamber Top Front

INDIVIDUAL PARTS

262 MCQ62096433 Damper CUTTING THERMOPLASTIC DVD NB45

263 MCQ62096483 Damper CUTTING THERMOPLASTIC HOME THE

266 AEJ75879401 Holder Assembly SPK SL8YG.DUSALLK HOLDER WI-FI

LCD801 EAJ63172305 LCD Module SMMD3276-A-00-VTNF-WX BACK LIG

CABLES

CABLE1 EAD62131542 Cable,FFC 26P050D-H01-0F01A-T 70 70MM 0.

CABLE2 EAD63970514 Cable,FFC AT05026090C04 90MM 0.50MM 26P

CABLE3 EAD63970513 Cable,FFC AT05026370C01 370MM 0.50MM 26P

CABLE5 EAD65366201 Harness,Single CAV-18-29 12507HS-H12G1 to 125
