LG SN8YG Service Manual

Copyright © 2020 LG Electronics Inc. All rights reserved.
Only for training and service purposes.
2-162-15
• Wireless subwoofer parts list
S AL LOCA. NO. PART NO. DESCRIPTION SPECIFICATION REMARKS
A900 TCG37388135 Active Woofer SPN8-W Print LG Logo SN8YG.DUS
A45W EBR89625801 PCB Assembly SPN8-W/SPN5B-W Woofer AMP+SMPS
A54W EAT63117401 Module,RF Full Module(RxTx) WL1NB6(TWBI-H002D) 0DBM 0DB 0%
OR
A54W EAT63117404 Module,RF Full Module(RxTx) WL1NB6_ 0DBM 0DB 0% 0A 0A 0DB
951 AGL77272902 Panel Assembly,Rear
SPK7-W WW COMMON_SL10YG.DDVEVN
953 EAD62131521 Cable,FFC 26P005D-H1-1F01A-T-60-60-0-0-0
954 EAG63233208 Socket,Power DAC-18JN08 2P STRAIGHT WIRE BK
961 MHK65448501 Sheet COMPLEX LDPE 20.6X15.6 2 0.5 T

LG SN8YG Specifications

General

Audio decoders	DTS Digital Surround, DTS Virtual:X, DTS-HD HR, DTS-HD Master Audio, DTS:X, Dolby Atmos, Dolby Digital, Dolby Digital Plus, Dolby TrueHD
Equalizer modes	Bass Blast, Bass Blast+, Standart
RMS rated power	440 W
Audio output channels	3.1.2 channels
Audio Return Channel (ARC)	Yes
Soundbar speaker RMS power	220 W
Subwoofer type	Active subwoofer
Subwoofer connectivity	Wireless
Ethernet LAN	No
HDCP version	2.2
Bluetooth version	4.2
Connectivity technology	Wired & Wireless
Digital audio optical out	1
FM radio	-
Display type	LCD
Product color	Black
Virtual assistant	Google Assistant
Audio formats supported	AAC, AAC+, FLAC, LPCM, MP3, OGG, WAV, WMA
Network streaming services supported	Chromecast
Mobile operating systems supported	Android, iOS
Cables included	Optical
Number of products included	1 pc(s)
Remote control battery type	AAA
Number of remote control batteries	4
Power source	AC
Soundbar power consumption	39.4 W
Power consumption (standby)	0.5 W
Subwoofer power consumption	36 W

Weight and Dimensions

Depth	119 mm
Width	1060 mm
Height	57 mm
Soundbar weight	4400 g
Subwoofer depth	312.8 mm
Subwoofer width	221 mm
Subwoofer height	390 mm
Subwoofer weight	7800 g
