Liebert 1000kVA - Figure 16 Monitor;MIMIC Display Example: Normal Power Flow

Operation
32
Figure 16 Monitor/Mimic display example: Normal power flow
UPS INPUT PWR
UPS RATINGS
A-B B-C C-A
BYPASS INPUT
A-B B-C C-A
LOAD
ABC
A-B B-C C-A
OK to Transfer
Static Switch Connected
OUTPUT VOLTAGE
ABC
627 K
V
A
/
502 KW
3OF3MODULES
CONNECTED
REDUND
A
NT
A-B B-C C-A
MOD 1 ON LINE
MOD 2 ON LINE
MOD 3 ON LINE
480V
480V
480V
480V
480V480V
480V
480V 480V
60.0 Hz
SCCB 1600
60.0 Hz
755A
755A
755A
UPS INPUT PWR
BATTERY
VOLTS 540
AMPS 15 CHARG
UPS RATINGS
A-B B-C C-A
OUTPUT VOLTAGE
LOAD
ABC
270 K
V
A
/
217 KW
A-B B-C C-A
480V 480V
480V
480V
480V
480V
60.0 Hz
350A
350A
350A
410A
410A
RATED 400 KVA
410A
AP648-84
SCC Display
Module Display
