Liebert HPS User Manual

pag. 7
7.2.3 --- R407C refrigerant units
7.2.3.1---Features of the refrigerating fluid R407C
At standard temperature and pressure it is a colourless gas
with low toxicity, non---flammable, and it has an allowed ex-
posure limit value (AEL/TLV) corresponding to 1000 ppm (av-
erage value measured on 8 hours/day). In the event of leak-
age, air the room before use.
Tab. e --- R407C refrigerant charge
Internal
unit
External
unit
R407C charge
(kg)
HPSC 060 2.2
HPSE 06
O
n
l
y
c
o
o
l
i
n
g
/
F
C
/
E
F
C
HPSC 06A 2.7
O
n
l
ycoo
l
i
ng
/
F
C
/
E
F
C
HPSC 06L 3.7
HPSC 080 2.7
HPSE 08
O
n
l
y
c
o
o
l
i
n
g
HPSC 08A 2.7
O
n
l
ycoo
l
i
ng
HPSC 08L 3.7
HPSC 080 3.0
HPSE 08
F
C
/
E
F
C
HPSC 08A 3.0
F
C
/
E
F
C
HPSC 08L 4.0
HPSE 10
HPSC 10A 2.7
H
P
S
E
1
0
Only cooling
HPSC 10L 3.7
HPSE 10
HPSC 10A 3.0
H
P
S
E
1
0
FC / EFC
HPSC 10L 4.0
HPSE 12
HPSC 12A 3.6
H
P
S
E
1
2
Only cooling / FC / EFC
HPSC 12L 4.6
HPSE 14
HPSC 14A 3.6
H
P
S
E
1
4
Only cooling / FC / EFC
HPSC 14L 4.6
IMPORTANT:
The charges indicated in Tab. e refer to a 2 m length for the
gas and liquid pipes: Tab. f shows the indications for longer
measures on the additional charge in grams of refrigerant
R407C by each pipe meter of the gas and liquid lines, accor-
ding to the diameters indicated in Tab. a.
Tab. f --- Additional charge in grams of refrigerant
R407C by meter of each line
Liquid line Gas line
Ø pipeline
(mm)
Add
charge
R407C g/m
Ø pipeline
(mm)
Add
charge
R407C g/m
φ
1
2
x
1
8
5
0
φ
1
6
x
1
4
0
φ 12 x 1 85.0 φ 16 x 1 4.0
φ
1
6
x
1
1
6
0
0
φ
1
8
x
1
5
5
φ 16 x 1 160.0 φ 18 x 1 5.5
---
--- φ 22 x 1 8.5
---
--- φ 28 x 1 14.5
The oil to be used when topping up is EMKARATE RL
32---3MA or MOBIL EAL ARTIC 22CC, if it’s unavailable use
an oil with the same characteristics (see Tab. g and Tab. h).
NEVER MIX DIFFERENT OILS TOGETHER. CLEAN THE PIP-
ING COMPLETELY BEFORE CHANGING THE TYPE OF OIL
USED.
Ta b . g --- E M K A R A T E R L 3 2 --- 3 M A o i l
viscosity at 40 _C
viscosity at 100 _C
viscosity index (ISO Grade)
:
:
:
31.2 cST
5.6 cST
32
Tab. h --- MOBIL EAL ARTIC 22CC oil
approx. specific weight (at 15_C)
flash point (C.O.C.)
pour point
viscosity index
viscosity at 40_C
viscosity at 100_C
:
:
:
:
:
:
0.99 kg/l
245 _C
< --- 5 4_C
116
23.6 cST
4.7 cST
7.3 --- Dismantling the unit
The machine has been designed and built to ensure continu-
ous operation.
The working life of some of the main components, such as
the fan and the compressor, depends on their maintenance.
If the unit has to be dismantled, this must be done by skilled
refrigerator technicians.
The refrigerating fluid and the lubricating oil in the circuit must
be disposed of in conformity with the laws in force in your
country.
7.4 --- Spare parts
We recommend the use of original spare parts.
When placing an order please refer to “Component List” en-
closed with the machine and specify the unit model and serial
no.
