Liebert HPS User Manual

pag. 29
Fig. 5 --- Electric connec ti ons
AC line output for
HPSC condensing unit
power supply
LAN plug
(Connectivity control option)
AC power supply
DC power supply (optional)
SC unit control
Powerface display
AC
(optional)
DC
Remote
display
HPSC
HPSE
Remote
display plug
(Standard control)
Hiromatic p lug
(Connectivity control option)
No. 2 holes for cable clips PG21
(option EFC 48Vdc / 230Vac)
No. 2 cable clips PG21
AC line input
EFC line input
(48Vdc / 230Vac)
Free
AC line input
Auxiliary input
No. 2 cable clips PG21
HPSC
HPSE
