Netlink Installation and Operation Manual
36 37
Installation and Operation
Appendix 2 – NS2 Board
The following pages cover the NS2 for use with the NL2 or NL4 NetLink module in FPA AC output systems.
A2.1 Mounting the NS2 Output Controller Accessory
Use the following procedure when mounting an NS2 Output Controller Accessory to a LifeSafety Power enclosure.
1. Locate the appropriate mounting holes in the enclosure and snap the four standoffs provided into the holes.
2. Align the board mounting holes (mounting hole locations are indicated in the drawing below) with the standoffs and snap
the board onto the standoffs. Be sure the board is properly oriented before snapping the board onto the standoffs.
NS2
NS2
Figure A2.1
