FlexPower DC Power System Installation Manual
14 15
User Certificate
Appendix 3 – UL Compliance Verification Sheet
General - All Applications:
1. The power supply must be installed within the protected
area.
2. The LifeSafety Model EB-80 must be used to house the
required battery(ies) when capacites of 40 to 80Ah are re-
quired. The EB-80 shall be mounted within 6ft of the power
supply and the wiring enclosed in conduit.
3. Connections to the SYS FLT, AC FLT, and FAI inputs shall
be completed within the same room, not exceeding a length
of 3m.
4. Do not connect equipment to an AC power source that is
controlled by a switch.
5. The LifeSafety Model BDM Battery Disconnect Module
must be used.
6. Trouble contacts shall be monitored by a listed alarm
system.
The following sections cover specific requirements based
on application:
UL1076, Proprietary Burglar Alarm Applications
1. The LifeSafety Model TS-20 tamper switch must be em-
ployed to monitor the power supply and EB-80 enclosures.
2. To achieve four hours of standby at full load current, 80Ah
min. battery capacity is required for the FPO150 or FPO250. To
achieve four hours of standby at full load current, 40Ah min.
battery capacity is required for the FPO75.
S319, Access Control Applications
The LifeSafety Model TS-20 tamper switch must be employed
to monitor the power supply and EB-80 enclosures.
For UL Compliance
Any locking device shall be configured for fail safe operation
upon occurrence of an alarm as shown in Activation with a Nor-
mally Closed Relay Contact in Sec. 1.3, FAI Input Usage.
